Dredging Pipe Floats
Dredging Pipe Floats are all reinforced materials with anti-corrosion, anti-freeze, anti-oxidation, and anti-purple line, and are not corroded by sea water, chemicals, pharmaceuticals, oil stains and aquatic organisms; strong bearing capacity, stable cylinder and durable. The service life of this product For more than 8 years, in addition to strong natural forces and artificial improper use, no maintenance or repair costs are required.
Category:
Products
Dredging Pipe Floats
Product Description
Feature：
1. Light weight and large buoyancy
2. Shock resistance, acid and alkali resistance
3. Easy to install and low cost for maintain
4.. a bright color to act as warning signs to other vessels in the vicinity.
5. Made in China
Key points of structure:
1. shell material: polyethylene
2 internal filler :PU
Galvanized bolts-nuts-washers
UV protection.
Application:for Pipe, Hose or Cable
1. Dredge floats are widely used for supporting suction/discharge hoses.
2.Used in many industries including mining, water treatment, sewerage, aquaculture and dredging.
3.uitable for floating cables, pipes and hose diameters from 25mm to 2600mm
|
PIPE FLOATER SPECIFICATION |
||||
|
NO |
FLOATER ID |
FLOATER OD |
FLOATER LENGTH |
NET BUOYANCY |
|
1 |
160mm |
500mm |
800mm |
220kg/pair |
|
2 |
180mm |
500mm |
800mm |
220kg/pair |
|
3 |
200mm |
500mm |
800mm |
220kg/pair |
|
4 |
225mm |
500mm |
800mm |
220kg/pair |
|
5 |
250mm |
600mm |
700mm |
260kg/pair |
|
6 |
280mm |
700mm |
900mm |
450kg/pair |
|
7 |
315mm |
800mm |
1000mm |
550kg/pair |
|
8 |
325mm |
1000mm |
1000mm |
650kg/pair |
|
9 |
355mm |
1000mm |
1000mm |
650kg/pair |
|
10 |
380mm |
1100mm |
1100mm |
850kg/pair |
|
11 |
400mm |
1100mm |
1100mm |
850kg/pair |
|
12 |
430mm |
1200mm |
1200mm |
1200kg/pair |
|
13 |
450mm |
1200mm |
1200mm |
1200kg/pair |
|
14 |
500mm |
1300mm |
1300mm |
1500kg/pair |
|
15 |
530mm |
1300mm |
1500mm |
1700kg/pair |
|
16 |
560mm |
1300mm |
1500mm |
1700kg/pair |
|
17 |
610mm |
1300mm |
1500mm |
1700kg/pair |
|
18 |
630mm |
1300mm |
1500mm |
1700kg/pair |
|
19 |
630mm |
1400mm |
1600mm |
2100kg/pair |
|
20 |
670mm |
1500mm |
1850mm |
2500kg/pair |
|
21 |
680mm |
1500mm |
1800mm |
2500kg/pair |
|
22 |
710mm |
1500mm |
1800mm |
2500kg/pair |
|
23 |
730mm |
1600mm |
1900mm |
2900kg/pair |
|
24 |
780mm |
1700mm |
2000mm |
2900kg/pair |
|
25 |
840mm |
1850mm |
2100mm |
3400kg/pair |
|
26 |
900mm |
2000mm |
2400mm |
4800kg/pair |
|
27 |
960mm |
2500mm |
2060mm |
5100kg/pair |
|
28 |
1000mm |
2500mm |
2060mm |
5100kg/pair |
